Connecting Alarm.com Wireless bridge to Wireless Network
WPS mode (1st Option)
Complete these steps to connect the W110 to the wireless network using WPS Mode.
1. Plug the W110 into a non-switched electrical outlet that is within close range of the customer’s Wi-Fi network/
router. Wait for the Power LED to begin blinking white.
2. Hold down the Communication button until the Wi-Fi LED turns off and the Communication LED begins blinking
green (approximately 2 to 6 seconds).
3. Activate the WPS Mode on the router. The W110 begins to connect to the wireless network.
4. Allow a few minutes for the W110 to connect. The Wi-Fi LED will turn solid white and the Communication LED will
turn solid camera green when a successful connection is made.
5. Connect the PoE camera to the Camera port at the bottom of the W110 using an Ethernet cable.
AP Mode (Alternative Option)
Complete these steps to connect the W110 to the wireless network using AP Mode
1. Plug the W110 into an electrical outlet that is within close range of the customer’s Wi-Fi network/router. Wait for
the Wi-Fi LED to begin blinking white.
2. On an Internet-enabled device, connect to the wireless network W110 (XX:XX:XX) where XX:XX:XX is the last six
characters of the W110’s MAC address, which is located on the back of the W110 or on the packaging.
3. On the same device, open a web browser and enter http://W110install in the URL field. Follow the on-screen
instructions to add the W110 to the wireless network.
4. Allow a few minutes for the W110 to connect. The Wi-Fi LED will turn solid white, and the Communication LED will
turn solid green when a successful connection is made.
5. Connect the PoE camera to the port at the bottom of the W110 using an Ethernet cable.
